The elegance of traditional siding & soffit with the strength of steel.
Flush-Lock Metal Soffit / Metal Siding offers a sleek, modern appearance with its smooth, flush wall profile and concealed fastener system. Designed for versatility, it can be installed vertically or horizontally, making it ideal for residential and commercial applications.
Beyond siding, Flush-Lock is available in solid and vented options making it perfect for soffits and under-decking, providing a clean, durable finish that enhances both aesthetics and performance.

_edited.png)

Lifetime Warranty
Flush-Lock painted steel siding and soffit carries a limited lifetime warranty on painted finishes. Unlike wood siding, Flush-Lock won't rot, warp, crack, or need repainting, so the finish you install is the finish you keep. Our warranty also covers excessive chalk and fade for three decades.
Made in America
Flush-Lock panels are roll-formed by True Metal Supply in Knoxville, Tennessee, using American steel and American-made Sherwin-Williams paint systems. Every order is cut to your exact lengths for siding, soffit, or under-deck ceilings, and ships to homeowners and contractors in all 50 states.
Energy Efficient
Flush-Lock's painted steel finish reflects more of the sun's heat than dark wood or vinyl, which helps reduce heat gain on sun-facing walls and porch ceilings. Its concealed-fastener design also installs tight over a weather barrier and insulation, helping your wall system perform as designed.
Cost
Effective
Flush-Lock steel siding and soffit is priced competitively with real wood siding, but it lasts much longer and skips the scraping, staining, and repainting wood needs every few years. It also resists rot, insects, and woodpecker damage, so you get the modern flush look of wood or fiber cement without the upkeep.
Don't compromise.
There's no denying the natural look of wood provides a stunning aesthetic. With digital prints, you can find the perfect grain or unique print for your building! Explore our digital print coatings to get the desired look you want with benefits of steel siding or metal soffit you need!
Gallery
Specifications
-
Profile
-
Option A: 12" net coverage with1/2" reveal
-
Option B: 12-1/2" net coverage, no reveal
-
Screw flange design, clips optional
-
Concealed fastened, tongue-and-groove design
-
Solid and vented options
-
Optional stiffening v-rib
-
-
Material
-
26ga, 24ga, 22ga KSI steel
-
.032, .040 aluminum
-
16oz copper
-
0.7, 0.8mm RHEINZINK® prePATINA Zinc
-
-
Coatings
-
AZ50 WeatherXL® SMP Finish
-
AAMA 2605 70% PVDF
-
AZ55 Galvalume® Mill Finish
-
Tru-Steel® HD Digital Coating
-
-
Warranty
-
Limited Lifetime Warranty on painted Flush-Lock panel material
-
-
Installation
-
Wall siding: vertical or horizontal
-
Soffit and porch/deck ceilings
-
Installs over solid substrate or framing
-
Standards
-
Material Standards
-
Galvalume® substrate per ASTM A792
-
Painted coil per ASTM A755
-
Steel is a noncombustible siding material
-
-
Applications
-
Residential, commercial, industrial cladding
-
Soffits and eaves
-
Porch ceilings and under-deck ceilings
-
Accent walls and interiors
-
